COOPER/EATON Micro Single Channel Input Unit ULMCIM
- Soft addressed
- Integral short circuit isolator
- Single address
- Suitable for monitoring:
flow switches / non fire inputs / auxiliary panels - Optional variant: ULMCIM-C
- No hard addressing required (plug and play)
- Quick and simple to install
- Compact size
Inquiry Form
We will get in touch with you shortly
Description
Description
Technical Data:
| Code | ULMCIM / ULMCIM-C |
| Description | Single Channel Input Units |
| Standards | UL864 9th edition |
| Current | 332µA |
| Operating Voltage | 24V dc |
| Voltage | 8.4Vpp (pulsed every 1 sec) |
| Current | 1.2mA |
| Trigger Resistance | 5.6kΩ |
| End Of Line Resistor | 22kΩ |
| Line Impedance | 16 (max) |
| Dimensions (H x W x D) | 65mm x 35mm x 18.5mm |
| Physical Weight | >0.1kg |
| Ingress Protection | IP40 |
